Camera
Sensor 1/3” black light CMOS sensor
Lens FullHD lens 2.8 mm @F2.0
Day&night IR cut filter with auto switch
Max. image resolution 1920x1080
Frame rate 1080P@25fps
Setting Saturation, brightness and contrast
Compression
Video compression H.265AI/H.265+/H.264
Bitrate Up to 6Mbps
Audio compression G.711a
Network
Alarm Motion detection, video loss
Ethernet 1 х 10/100Mbps Ethernet port
General
Temperature -10°C~60°C
Humidity 10%-90%
Power supply DC12V±10%/POE
IR range 24 led lamps “IR2”:20-30 meters
Consumption MAX 5W
Material Metal
Ingress Protection IP67
Weight 290g
Dimension 96mm х 73mm
Camera
Sensor 1/3” black light CMOS sensor
Lens FullHD lens 2.8 mm @F2.0
Day&night IR cut filter with auto switch
Max. image resolution 1920x1080
Frame rate 1080P@25fps
Setting Saturation, brightness and contrast
Compression
Video compression H.265AI/H.265+/H.264
Bitrate Up to 6Mbps
Audio compression G.711a
Network
Alarm Motion detection, video loss
Ethernet 1 х 10/100Mbps Ethernet port
General
Temperature -10°C~60°C
Humidity 10%-90%
Power supply DC12V±10%/POE
IR range 24 led lamps “IR2”:20-30 meters
Consumption MAX 5W
Material Metal
Ingress Protection IP66
Weight 300g
Dimension 166mm х 60mm х 60mm
Camera
Sensor 1/2.9” Progressive Scan CMOS
Lens FullHD lens 4mm,@F2.0
Day&night IR cut filter with auto switch
Max. image resolution 1920x1080
Frame rate 1080P@25fps
Setting Saturation, brightness and contrast
Compression
Video compression H.264
Bitrate Up to 6Mbps
Audio compression G.711a
Network
Alarm Motion detection, video loss
Ethernet 1 x 10M/100M Ethernet, RJ45 Port, Wi-Fi(IEEE802.11b/g/n)
Audio Input 1 Channel Internal MIC
Audio Output 1 Channel Internal Speaker
TF Card Support
Reset Support
Function
Exposure Mode Auto
Automatic Gain Control Auto
White Balance Auto
Motion Detection Support
Day-Night Vision IR-CUT, Supports color/black switch
Remote control Enable motion detection, Enabled PUSH notifications, managing network and picture settings
Detection Alarm PUSH-Notifications to mobile app, web interface, message
Storage Up to 128GB
Pan/Tilt Pan: 345° Tilt: 117°
General
Temperature -10°C~55°C
Humidity RH 10%~90%
Power supply DC5V/1.5A
IR range 8 led, 10 meters
Consumption Day<3W, Night<6W
Material White/ABS+PC
Ingress Protection IP54
Weight 190g
Dimension 65mm x 60mm x 108.5mm
